Happymodel 2.4g omnidirectional antenna for ELRS - 40mm

Happymodel 2.4g omnidirectional antenna for ELRS - U.FL also compatible with TBS Tracer, 40mm in length.

Check out our ExpressLRS Collection, all our Receivers and the rest of our Happymodel Products!

Specifications:

• Frequency  (MHz): 2400.0
• Efficiency (dBi): -0.89
• Gain (dBi): 2.23
• Efficiency (%):  81.46
• Directivity (dB): 5.12
• Peak Gain Position (Theta): 180.00
• Peak Gain Position (Phi): 330.00
• Efficiency ThetaPol (%) : 20.90
• Efficiency PhiPol (%) : 60.56
• Upper Hem. Efficiency (%) : 39.93
• Lower Hem. Efficiency (%) : 41.54
• Connector : IPEX/IPX/U.FL
• Antenna width: 52mm
• Antenna length: 40mm

Package Includes:

• 1 x Happymodel 2.4g omnidirectional antenna for ELRS - 40mm
