RadioMaster Zorro EdgeTX RC Transmitter - ExpressLRS Starter Set (Black)
RadioMaster Zorro Radio - The Compact Class-Leader.
This is the listing for the Zorro radio and three ELRS 2.4GHz receivers. One ceramic antenna receiver and two T-antenna receivers. The radio can be perchased on its own at the following LINK.
This is the ExpressLRS version and the two 18350 batteries required to power the radio are sold separately HERE
Featuring an ergonomic design, large bright LCD screen in the perfect viewing position, travel adjustable HALL sensor gimbals, a nano size external RF module bay, built-in USB-C Charging, USB-C Data port for updating and playing simulators, rear and top assignable push buttons, scroll wheels, RadioMaster's 7 button menu navigation system, headphone audio output, external power source input and a host of RF options the RadioMaster Zorro is set to change the game once again.
This is the ExpressLRS 2.4GHz version which is awesome for those that are looking to push the limits of range and latency. ELRS is an open source transmission system with unrivaled capabilities. For the pro pilots or those simply seeking the best performance and link reliability, ELRS is definitely the right choice for you!
Check out all our ExpressLRS Products, Radios and the rest of our RadioMaster Collection!
Features
- External Module Bay Supports TBS / ELRS
- Improved Metal Roller for Precise Control
- Supports External 2S Power Supply
- Supports USB-C direct charging
- Supports OPENTX & EDGETX
- 18350 Battery Compartments
- Ergonomically Designed
- Adjustable Hall Gimbals
- Oversized LCD Screen
- Soft Leather Grips
- Foldable Antenna
- ELRS Model
Specifications
- Module bay: Nano size (Compatible with TBS Nano Crossfire / Nano Tracer / IRC Ghost)
- Firmware Upgrade method: Via USB or SD card (SD Not included)
- RF power: TBA (CE and FCC Version will be available)
- Operating system: OpenTX / EdgeTX Compatible
- Control channels: Maximum 16 (Rx dependent)
- Operating frequency: 2.400GHz-2.480GHz
- Physical dimensions: 170*159*108mm
- Charging: Built-in USB-C Charging
- Display: 128*64 Monochrome LCD
- Operational current: [email protected]
- Operational voltage: 6.6-8.4v DC
- Battery: 2 x 18350 (Not included)
- Supported protocols: ELRS
- Internal RF Options: ELRS
- Antenna gain: Folding 2db
- Control distance: TBA
- Weight: 350 grams
- Gimbal: Hall-effect
Includes
- 1 x Radio Master Zorro EdgeTX RC Transmitter - ExpressLRS (Black)
- 2 x EP1 Full Range 2.4GHz ELRS Receiver W/ T-antenna
- 1 x EP2 Compact 2.4GHz Receiver W/ Ceramic Antenna
